Carbon capture, utilization, and storage (CCUS) technology has become an increasingly critical tool for reducing greenhouse gas emissions and mitigating climate change. As countries work to meet emissions reduction targets and transition to cleaner energy systems, CCUS provides a mechanism for capturing carbon dioxide from industrial processes or power generation before it is released into the atmosphere.

This technology enables carbon dioxide to then be permanently stored deep underground or put to productive use. With multiple benefits such as improving industrial efficiency, CCUS is poised to play a vital role in achieving a low-carbon future if deployed at scale. This article will provide an in-depth look at the current state of CCUS technology and the promise it holds for significantly reducing emissions across multiple industries and Applications.

Find Global CCUS Projects and Tenders Get Started Now!

What Is CCUS Technology?

Carbon capture, utilization, and storage (CCUS) technology involves capturing carbon dioxide ( CO2) emissions from sources like coal power plants or industrial processes and either using them for another purpose or storing them so they are not released into the atmosphere.

Capture: The first step in CCUS is capturing the CO2 emissions before they are released into the air.  CO2 can be captured from concentrated sources, like the flue gas from coal power plants and industrial processes like cement and steel production. Technologies like chemical absorption, adsorption, and membrane separation are used to separate the  CO2 from other gases. The captured  CO2 is then compressed into a liquid or supercritical fluid for transport and storage.

Utilization: Rather than storing the captured  CO2, it can be used to make useful products. The  CO2 can be used to produce chemicals like methanol and formic acid, synthetic fuels like methane and methanol, building materials like concrete, and enhanced oil recovery to extract more oil from depleted oil fields. Using the  CO2 in these ways creates economic value and offsets some of the costs of implementing CCUS technology.

Storage: When the  CO2 cannot be utilized, it must be stored to prevent its release into the atmosphere. The most promising storage method is geological storage, where  CO2 is injected into deep underground rock formations like depleted oil and gas reservoirs or deep saline aquifers.  CO2 can also be mineralized and stored in solid form by reacting it with metal oxides to produce stable carbonate minerals. These storage methods can store  CO2 for long periods of time and keep it isolated from the atmosphere.

CCUS technology provides a way to reduce CO2 emissions while still using fossil fuels. When combined with other technologies like renewable energy, CCUS can help meet emissions reduction targets and mitigate climate change. With more research and development, costs can be lowered so CCUS can be deployed on a large scale.

Read: Mitsubishi Heavy Industries and Worley Awarded FEED Contract for UK’s First Carbon Capture Plant

How Does CCUS Work to Reduce Emissions?

Carbon capture, utilization, and storage (CCUS) is the process of capturing carbon dioxide (CO2) from industrial sources before it enters the atmosphere and then transporting and storing it in underground geological formations. CCUS is a critical tool for reducing CO2 emissions and mitigating climate change.

Capture

The first step in CCUS is the capture of  CO2 from large industrial sources like coal-fired power plants, natural gas power plants, oil refineries, and other industrial processes. The captured  CO2 is separated from other gases and purified into a concentrated stream of  CO2 that is suitable for transport and storage.  CO2 can be captured post-combustion from power plant flue gases, pre-combustion from syngas, or by using oxy-fuel combustion.

Transport

The captured  CO2 is next compressed into a liquid for efficient transport, typically via pipeline.  CO2 pipelines are commonly used to transport  CO2 over long distances for oil recovery operations. For CCUS,  CO2 pipelines deliver the  CO2 from the source of capture to a storage site.

Storage

Geological storage involves injecting the captured CO2 deep underground into porous rock formations, where it is trapped and permanently stored. Depleted oil and gas reservoirs and deep saline formations can securely store  CO2 for thousands of years. Monitoring is required to ensure the  CO2 remains permanently trapped. The storage site is carefully selected based on its ability to securely trap CO2 and its proximity to  CO2 sources and pipeline routes.

CCUS is a key technology for reducing CO2 emissions from heavy industries like power generation and manufacturing. By capturing and storing  CO2 that would otherwise be emitted to the atmosphere, CCUS can help mitigate climate change while allowing the continued use of fossil fuels. With supportive policies and economic incentives, CCUS can achieve greater deployment and make a substantial contribution to climate change mitigation.

Also Read: Understanding Global CO2 Emission and Its Multifaceted Risks

Major Components of a CCUS System

Carbon capture, utilization, and storage (CCUS) technology involves three main components: capture, transport and storage.

Capture refers to the process of separating  CO2 from industrial emissions before they are released into the atmosphere. The captured  CO2 is then compressed and converted to a liquid or supercritical fluid for transport to a storage site. Finally, the  CO2 is injected and securely contained in geological formations for long-term storage.

CO2 capture can be accomplished using three main technologies: post-combustion, pre-combustion and oxyfuel combustion. In post-combustion capture,  CO2 is separated from stack emissions after the combustion of the fossil fuel. Chemical solvents are used to absorb the  CO2, which is then released from the solvent and compressed for storage. Pre- combustion capture involves reacting a fossil fuel with oxygen or air and steam to produce hydrogen and  CO2. The  CO2 is captured before the hydrogen is used as fuel. Oxyfuel combustion uses pure oxygen rather than air for combustion, producing a stream of  CO2 and water vapor from which the  CO2 can be separated and captured.

Once captured, the  CO2 is transported via pipelines, ships, rail or trucks to suitable storage sites, often located near the source of emissions or in depleted oil and gas fields. Geological formations that can securely store  CO2 include deep saline aquifers, depleted oil and gas fields, and abandoned or depleted coal seams. Saline aquifers and depleted oil/gas fields are most commonly used for large-scale  CO2 storage.

When applied together, these components can capture up to 90% of emissions from industrial sources and power plants, significantly reducing the amount of  CO2 released into the atmosphere. Widespread deployment of CCUS technology will be crucial for achieving net-zero emissions and mitigating climate change.

Importance of CCUS

According to the Intergovernmental Panel on Climate Change, CCUS could contribute between 4% to 38% of the cumulative  CO2 reductions required by 2050 to have a reasonable chance of limiting global temperature rise to 1.50C. Widespread deployment of CCUS, especially when combined with other technologies like renewable energy, can help significantly cut emissions from power generation and heavy industry. For some industrial sectors, CCUS may be the only viable path to decarbonization.

CCUS is a critical tool for reaching net-zero emissions and avoiding the most catastrophic consequences of climate change. With more pilot projects and commercial-scale demonstrations, costs can decrease, enabling broader adoption of CCUS worldwide. Continued policy support, research and development, and public-private partnerships are still needed to help scale and optimize this important set of technologies.

Challenges and Limitations of Implementing CCUS

Cost and Economic Feasibility

The challenges associated with implementing CCIJS technology at scale are primarily economic. Capturing, transporting, and storing  CO2 requires specialized equipment and infrastructure, which can be cost-prohibitive. Studies estimate the cost of capturing  CO2 from coal and natural gas power plants ranges from S50 to SIOO per ton of  CO2- The transportation and storage components add additional costs.

For CCUS to be viable at a large scale, costs must decrease substantially. Government policies that place a price on carbon emissions or provide financial incentives for CCUS projects can help improve the economic feasibility.

Lack of Infrastructure and Technology Maturity

Existing CCUS projects are limited to small-scale demonstrations or retrofits of industrial facilities. Widespread deployment will require investments in  CO2 capture technologies for various point sources, transportation networks, and geologic storage sites-  CO2 capture technologies, though improving, need to advance further to minimize efficiency and cost impacts.

Similarly, more work is needed to characterize geologic formations suitable for  CO2 storage and ensure their long-term containment. Scaling up CCUS will take time as technologies mature and infrastructure develops.

Health, Safety and Environmental Risks

Although the risks are manageable with proper safeguards, the perception of risks associated with  CO2 transportation and storage may hinder public acceptance of CCUS-  CO2 pipelines and injection sites require monitoring and risk management plans to minimize hazards like leaks or seismic activity. Strict regulations on  CO2 storage are also important to guarantee its permanent containment and avoid potential environmental impacts. Communicating accurate scientific information about CCUS risks and benefits to stakeholders and communities can help address concerns.

CCUS has significant potential as a tool for reducing CO2 emissions and mitigating climate change. However, cost, infrastructure, and policy barriers must be overcome through technology innovation, demonstration projects, and government support for this potential to be realized. With continued progress, CCUS can play an important role in a portfolio of solutions for decarbonizing the energy system and heavy industries.

CCUS Storage Options: Geological, Ocean, Mineralization

The storage of carbon dioxide captured through CCUS technology requires secure and permanent options to avoid accidental release into the atmosphere. storage involves injecting compressed  CO2 deep within porous rock formations, depleted oil and gas reservoirs, or saline aquifers. Studies show geological storage can retain over 99% of injected  CO2 for 1000 years. However, site selection and monitoring are crucial to minimize risks like leaks or induced seismicity.

Ocean storage dissolves CO2 in deep ocean waters or converts it to solid mineral carbonates. While the ocean has a vast capacity to store  CO2, this method raises concerns about the marine environment's impact and permanence. Mineral carbonation or mineralization converts gaseous CO2 into solid minerals such as calcite by reacting it with metal oxide minerals. This provides a permanent storage solution but requires abundant reactive minerals and a cheap source of magnesium or calcium.

Geological storage is the most promising option currently based on its ability to store industrial volumes of CO2 for the long term. However, a combination of multiple storage approaches may be needed to achieve the necessary emissions reductions to mitigate climate change. Ongoing research and pilot projects are still required to reduce costs, ensure safety, and gain public acceptance of CCUS technology and its associated storage methods as a critical tool for emissions reduction.

The options for the storage of carbon dioxide are diverse but also face technical, economic, and social challenges. With continued innovation and demonstration, CCUS can achieve its potential as a key technology for tackling climate change and enabling a sustainable energy system. Overall, identifying and developing appropriate storage methods alongside CCUS technology itself is crucial to overcoming barriers to widespread adoption.

Global CCUS Projects and Deployments

CCUS technology has been deployed at a commercial scale at several locations around the world. Some of the largest CCUS projects in the world are mentioned below.

Sleipner Project

This CCUS project in Norway, operated by Equinor in Norway, captures  CO2 from natural gas production and stores it in a deep saline aquifer in the North Sea. It has stored over 20 million tonnes of  CO2 since 1996.

Gorgon Project

This CCUS project in Australia, operated by Chevron, captures  CO2 from natural gas production and stores it in a deep saline aquifer. It can store 4 million tons per year.

Illinois Industrial CCS Project

This CCUS project in the US captures  CO2 from an ethanol plant and stores it in a deep saline aquifer. It has stored over 1 million tons of  CO2 since 2017.

Cost and Deployment Challenges

While CCUS technology has been proven at a commercial scale, costs remain high, and widespread deployment faces several challenges. The additional equipment and processes required for capture transport, and storage of  CO2 can consume 20-30% of the energy output from a power plant or industrial facility. This significantly reduces the net power and increases costs.

Transporting and storing  CO2 also requires the development of pipeline networks and underground storage sites, which face regulatory, environmental, and public acceptance challenges. However, many experts argue that CCUS will be essential for achieving long-term climate change mitigation goals, given the scale of emissions from some industrial sectors and the challenges of transitioning to zero-carbon energy and transportation systems.

If costs can be reduced and other challenges addressed, CCUS has the potential to make a substantial contribution to global climate change mitigation efforts. With continued technology development and policy support, costs are projected to decrease over time, improving the economic viability and competitiveness of CCUS.

Find Global CCUS
Projects and Tenders  Get Started Now!

Role of CCUS in Reaching Net Zero Emissions

Carbon capture, utilization, and storage (CCUS) technology refers to methods and processes that capture carbon dioxide ( CO2) emissions from sources like power plants and industrial facilities and then stores them so they are not released into the atmosphere- CCUS is considered crucial for achieving net-zero emissions and mitigating the worst effects of climate change.

Capturing Carbon Emissions

CCUS encompasses technologies that can capture up to 90% of  CO2 emissions produced from the use of fossil fuels in electricity generation and industrial processes like cement production. The captured  CO2 is then compressed and transported for storage or use.  CO2 can be captured pre-combustion, post-combustion, or through oxy-fuel combustion.

Storing and Utilizing Captured Carbon

Once captured, the  CO2 is transported to a storage site and injected into deep geological formations, a process known as geological sequestration. Depleted oil and gas fields and deep saline aquifers are commonly used for storage.  CO2 can also be utilized for various commercial purposes, such as in enhanced oil recovery to extract hard-to-reach oil deposits. Some  CO2 is used to make fuels, chemicals, building materials, and other products.

Policies and Incentives Driving CCUS Adoption

Governments and policymakers around the world have implemented policies and incentives to drive the adoption of carbon capture, utilization, and storage (CCIJS) technology. Tax incentives, such as tax credits, tax exemptions, and tax deductions have been offered to companies that invest in CCUS projects. For example, Section 450 tax credits in the U.S. provide up to $50 per metric ton of  CO2 captured and stored. The 450-tax credit has catalyzed investment in CCUS, with over 30 projects in development across various industries.

Grants, loans, and loan guarantees are other policy mechanisms used to fund CCUS demonstration projects. For instance, the U-S- Department of Energy's Loan Programs Office and the European Commission have provided loans and grants for first-of-a-kind projects. Government funding helps de-risk expensive, capital—intensive projects, enabling private-sector investment.

Cap and trade programs that place a price on carbon emissions have also driven interest in CCUS. Companies can meet their emissions targets by capturing and storing  CO2 and then selling any excess emissions credits. For example, California's LOW Carbon Fuel Standard incentivizes the use of captured  CO2 to produce Iow-carbon transportation fuels. The European Union’s Emissions Trading System allows certain CCUS projects to generate tradable emissions credits.

Performance standards that mandate emissions reductions have motivated companies to explore CCUS options. For example, the EPA's New Source Performance Standards require new coal-fired power plants in the U.S. to achieve emissions limits that can only be met using CCUS technology. Several countries have announced net-zero emissions targets, which will require widespread CCIJS deployment across energy-intensive industries like cement and steel production.

Government policies and incentives are crucial for stimulating investment in CCUS projects. Although CCUS technology is not yet widely commercialized, supportive policies can help drive cost reductions, enabling broader adoption of this critical tool for mitigating climate change.

Read: Petrofac Secures FEED for Netherlands Aramis CCS Project

CCUS Technology FAQs

CCUS technology is critical for reducing industrial  CO2 emissions and mitigating climate Change. However, there are many misconceptions about how CCUS works and its potential impact. Here are answers to some of the most frequently asked questions about CCUS technology.

What is CCUS and how does it work?

CCUS stands for carbon capture, utilization, and storage. It is an integrated suite of technologies that captures carbon dioxide ( CO2) emissions from sources like coal and gas power plants or industrial processes and either recycles them into products, uses them for enhanced oil recovery, or stores them underground. Capturing  CO2 prevents it from entering the atmosphere and warming the planet.

How much  CO2 can CCUS technology capture?

capture up to Of the  CO2 emissions from industrial sources. Several large-scale CCUS facilities currently operating can capture over I million tons of  CO2 annually. With further development and deployment, CCUS can capture billions of tons of  CO2 per year from power plants and industrial sources, significantly reducing emissions.

What are the benefits of implementing CCUS?

CCUS provides major environmental and economic benefits. It helps mitigate climate change by reducing  CO2 emissions, the primary greenhouse gas contributing to global warming. It allows for continued use of fossil fuels in a carbon-constrained world. It also creates new industries and jobs in the green economy around  CO2 capture, transportation, utilization, and storage.

What is the current status of CCUS technology?

CCUS technology has been used in various industries for years. However, to achieve climate change mitigation on a large scale, CCUS must be deployed much more widely. Many new commercial-scale projects are currently in development around the world. Government support and policies like tax incentives are critical to accelerating the broad adoption of CCUS technology. With increased deployment and funding, CCIJS can become a vital tool for significantly reducing  CO2 emissions and meeting global climate goals. By capturing and storing billions of tons of  CO2 per year, CCUS technology may help create a more sustainable future for our planet.

Conclusion

Carbon capture, utilization, and storage are critical technologies that can help achieve emissions reduction goals in the coming decades. While some argue it is too expensive or unproven, the potential benefits outweigh the concerns. The technology already exists and simply needs further development and deployment. With the right investments and policies, CCUS can scale rapidly. Support from both government and industry Will be key to enabling this important climate solution. Widespread CCUS will not only reduce emissions from major sources like power plants and factories but also open up opportunities to create valuable products from waste carbon. The technology promises environmental and economic wins. CCUS is not the only solution, but it is an essential piece of a net zero future. With a concerted effort, CCUS can move from promise to reality.
