A cleanroom is a highly controlled and sterile environment designed for the manufacturing of electronic components, particularly semiconductors. It is a facility where air quality, temperature, humidity, and other environmental factors are tightly regulated to ensure the utmost cleanliness. The objective is to minimize contaminants such as dust, particles, and airborne microbes, as these can adversely affect the precision and functionality of semiconductor devices.

Cleanrooms typically feature advanced air filtration systems, specialized clothing for personnel, and strict protocols for entry and exit. The cleanliness standards are specified by the number of particles per cubic meter at various size ranges.

Commonly used in the production of microprocessors, memory chips, and other electronic components, cleanroom standards play a critical role in ensuring the reliability and performance of modern technology. The controlled conditions within these facilities enable the intricate processes of photolithography, etching, and deposition to take place with a high degree of accuracy, contributing to the advancement of the electronics industry.

What Happens in a Semiconductor Cleanroom?

Production of semiconductor chips revolves around semiconductor cleanrooms. Within these sterile environments, specialists carry out a range of duties, such as:

Wafers

The production of silicon wafers and their subsequent processing are carried out in cleanrooms.  A Silicon wafer is a piece of material that is very thin and serves as the foundation for semiconductor chips.

Making a Mask

Developing and utilizing photomasks to imprint circuit designs onto semiconductor fabs is a phenomenon that takes place in the semiconductor cleanrooms.

Deposition

The cleanrooms are also used for the process of deposition. During this stage of the manufacturing process, thin layers of various materials are placed on a wafer or substrate.

Etching

The process of etching is carried out in cleanrooms for semiconductors. Wafers are cleaned during this process to facilitate the creation of precise circuit designs.

Cleaning

As the name suggests, cleanrooms are environments where wafers and other pieces of equipment are maintained clean to prevent infection and increase the efficiency of chips being manufactured.

Testing

The process of testing is also carried out in semiconductor cleanrooms. Completed wafers are checked to ensure that they meet the desired standards.

Read: A Comprehensive Guide to the Fabless Semiconductor Industry

Key Requirements for Cleanrooms

It is necessary to fulfill several prerequisites in the cleanrooms to manufacture chips of the highest quality. When it comes to a cleanroom for semiconductors, the following are some of the most important requirements:

• Airborne particle concentration -  clean air is a major requirement for semiconductor cleanrooms. They should be free from particulate matter to prevent cleanroom contamination. It must be less than 3,520 particles 0.5µm or smaller per cubic meter of air (ISO 5. Air cleanliness plays a pivotal role in production quality.
• Temperature Control - There should be precise control over the temperature. The specified temperature should be between 20°C ± 1°C.
• Humidity - To maintain stable manufacturing conditions, the humidity level must be kept in mind. The specified humidity required in the semiconductor cleanroom should be between 40% ± 5% RH.
• Air velocity - Proper air circulation and airflow are crucial for removing particles and airborne microbes. The air velocity must be 20-50 feet per minute.
• ESD control - Implementing measures to control electrostatic discharge (ESD) is necessary. It is done to protect sensitive semiconductor components. It should be less than 20 volts.

Contamination control in cleanrooms

The following are some of the important features that are included in the cleanrooms to control contamination:

• The HEPA filters: All sub micron particles in the air that are 0.3 microns or larger are removed from the air by these filters 99.97%.
• Filters that have an ultra-low particle count (ULPA): To a degree of 99.9995%, these filters exclude from the air all particles that are 0.1 micrometers or larger.
• Management of both temperature and humidity: To prevent wafer warping and other faults, temperature and humidity must be brought under strict control.
• Controlling the flow of air: To stop the spread of contamination, the air is filtered very carefully and then channeled into the cleanroom.
• Control by means of electrostatic discharge (ESD): Because electrostatic discharge (ESD) can cause harm to sensitive electronic components, cleanrooms are designed to reduce the amount of static electricity that is present.

Find Global Semiconductor projects and tenders Get Started Now!

Semiconductor Cleanroom Classification

It is possible to categorize cleanrooms according to the degree of cleanliness they possess using ISO standard. A standard for cleanroom classification has been established by the International Organization for Standardization (ISO).

ISO 1, ISO 2, ISO 3, ISO 4, ISO 5, ISO 6, ISO 7, ISO 8, and ISO 9 are the clean room classes. ISO 1 is considered to be the "cleanest" class, while ISO 9 is considered to be the "dirtiest" class.

This cleanroom standard is classified according to the number of particles that are present in one cubic meter of air. ISO 5 and ISO 6 cleanrooms are the most prevalent types of cleanrooms used in the semiconductor manufacturing industry.

Benefits of Cleanrooms

A cleanroom can be a costly and time-consuming endeavor to design and build. The expense of a cleanroom is, however, more than justified by its many advantages. Cleanrooms are useful for:

1. Boost productivity: Cleanrooms can boost IC production by decreasing contamination.
2. Minimize flaws: By reducing the number of flaws in ICs, cleanrooms can help to produce higher-quality goods.
3. Enhance efficiency: To reduce the impact of contamination, cleanrooms can help ICs function better.

The Future of Cleanrooms

As semiconductor devices continue to shrink in size, they will most likely influence the development of cleanroom standards in the future. More and more pristine settings will be required as transistors shrink in size and complexity. Cleanroom technology may see certain developments in the future, such as:

• Innovative methods of filtration technology: To remove even more minute particles from the air, newly developed filtration technologies will be required.
• Monitoring and cleaning systems that are totally automated: In the future, automation will play an increasingly significant part in the operations of cleanroom facility
• Monitoring of ongoing contamination in real time: In the event of contamination occurrences, early warning will be provided by real-time monitoring programs.
• Robotics and other forms of automation: It is anticipated that robots and other forms of automation will be utilized to carry out tasks that are currently carried out by people.
• Construction and design of cleanrooms: In order to produce cleanrooms that are even more advanced in terms of cleanliness and efficiency, new materials and construction methods will be utilized.

Conclusion

Cleanrooms are an essential component of the semiconductor industry. To ensure that the chips produced in a semiconductor fab are of high quality, cleanroom design must be a priority. Therefore, investing in setting up state-of-the-art cleanrooms is necessary for the entire semiconductor manufacturing process. lately, top semiconductor manufacturing companies are investing in setting up world-class semiconductor fab facilities. Check out recent developments in the semiconductor manufacturing sector around the world.

Frequently Asked Questions (FAQs)

Here are some of the frequently asked questions,

Why are cleanrooms necessary in semiconductor manufacturing?

During the production operations of semiconductors, cleanrooms are required in order to prevent contamination from developing. These extremely delicate components can be negatively affected by even the smallest particles.


How are semiconductor cleanrooms classified?

It is possible to categorize cleanrooms according to the maximum permitted particle count per cubic meter of air that they contain. ISO Class 1 (with the fewest particles) and ISO Class 9 (with the highest particle count) are the categories that are available.

What are some of the challenges of operating a cleanroom?

The operation of a cleanroom has a number of obstacles, including the necessary maintenance of cleanliness and the regulation of temperature.

What is the purpose of a semiconductor cleanroom?

A cleanroom is a controlled environment that filters contaminants such as dust, airborne germs, and aerosol particles in order to create the cleanest area that is possible.

What are the different classes of clean rooms?

ISO 1, ISO 2, ISO 3, ISO 4, ISO 5, ISO 6, ISO 7, ISO 8, and ISO 9 are the clean room classes that are included in this ISO standard. ISO 1 is considered to be the "cleanest" class, while ISO 9 is considered to be the "dirtiest" class. An ISO 9 clean room environment is cleaner than a standard room, even if it is considered to be the "dirtiest" type of clean room environment.
